Gyprock Flexible Plasterboard

Auckland

402.9K profile views
52 saves

Gyprock Flexible Plasterboard is a 6.5mm plasterboard sheet with an enhanced gypsum core in a heavy duty liner paper that enables the board to bend to a small radius. This plasterboard is installed in two layers for increased strength and the long edges of the panels are recessed for flush jointing to a smooth, continuous surface.

Tags

plasterboard flexible plasterboard continuous surface commercial construction plaster

Product Details

Product: Gyprock Flexible Plasterboard
Category: Suspended Ceiling
Sold by: CSR Potter Interior Systems
Range: Plasterboard

Product Variants

Colors
Material
Size

CSR Potter Interior Systems is specified by

Visit site

Gyprock Flexible Plasterboard is a 6.5mm plasterboard sheet with an enhanced gypsum core in a heavy duty liner paper that enables the board to bend to a small radius.

This plasterboard is installed in two layers for increased strength and the long edges of the panels are recessed for flush jointing to a smooth, continuous surface.

Specs: Board Weight 4.3kg/m2

Thickness 6.5mm

Width 1200mm

Length 3600mm

Thermal Performance – R Values 0.03m2K/W

Fire Hazard (accessed to AS/NZS3837 cone calorimeter test) Group Number 1S | ASEA < 250 m2/kg | Report Ref WFRA 45759
Scope of use: Typical applications

Curved walls and ceilings

Freeform bulkheads and features
Installation: Gyprock Flexible Plasterboard is typically installed in two layers for a 13mm thick final lining thickness allowing it to match other lining thicknesses in commercial contruction.

This installation can accommodate a 250mm radius design for a convex curve and 450mm radius for a concave curve.
