PureCoat™

Bates Surfaces
Visit Website

PureCoat™ by Bates Surfaces is a durable MDF panel finished in a high-quality architectural UV coating. PureCoat panels are available in a range of solid colours, and finishes from mirror gloss to matt, with a colour-matched reverse side.

Warm White
L2440 x W1220 x H18 mm
Details
General
  • Type of use
    Commercial and Residential
Scope of use

PureCoat panels are suitable for vertical applications, including drawers, cabinet doors, wall linings and large feature panels, as well as walls, kitchens and laundries in residential and commercial settings. For internal use only.

Features

An architectural finish

PureCoat™ delivers a high-end pure colour, with a depth of finish that outperforms almost all solvent-based processes. Because the paint is dried instantly on the UV line, these panels all arrive on site with a uniform quality finish. PureCoat is resistant to stains and fading, contains anti-fingerprint technology, and offers a much higher resistance to scratching than traditional paint systems.

A healthier process

Using the latest UV technology, our process bonds the coating into a moisture-resistant, E0 low-formaldehyde-emitting MDF substrate. There are no VOCs or Red List chemicals involved, making for a healthier product on site and a safer working environment in the factory. Because UV technology offers more consistent quality control, this also means less wastage than with traditional processes.

Protec+ antimicrobial surfaces

PureCoat™ surfaces contain Protec+ antimicrobial technology. Impregnated with silver ions that minimise the spread of bacteria, mould and mildew, these long-term antimicrobial properties make PureCoat ideal for applications where hygiene is critical. With this effective layer of protection, the environment is less hospitable to harmful bacteria and the risk of cross-contamination is greatly reduced.

Bespoke colours & matched edging

In addition to the colours in the main collection, we can create bespoke colours for larger projects. The PureCoat™ collection has matching PVC and laser edging available, offering edge protection and impact resistance. Some designers also like to use a contrasting edging, such as the plywood edge tape.

Product details

Dimensions and edging

PureCoat panels measure 2440mm × 1220mm × 18mm, feature an MRZero MDF substrate, and are available with PVC or laser edging in a range of colours and finishes. PVC edging measures 1mm × 21mm, while laser edging measures 1.2mm × 22mm.

Visit Website

About the
Seller

Bates Surfaces has been a leader in surface-coating building products since 1953. Today, we use the best UV-coating technology in the world and own one of the largest production lines in Australasia.

New Zealand’s largest applicator of UV coatings and a trusted supply partner to the local products industry for over 70 years.

We transform products, such as raw fibre cement panels, into pre-finished, factory-coated products – working with manufacturers as they make them part of their product catalogue.

In addition to fulfilling OSM orders for customers such as James Hardie and Laminex, we market our own brands – PureCoat™ kitchen and bathroom panels, PlyPlay™ pre-finished plywood wall and ceiling panels, and hygienic Fenta™ Ceiling Tiles.
