LOX High Security Electric Strike is designed for use with all access control systems. Retrofit compatible with FSH and Padde Australian Footprint strikes. It comes with a 10mm strike lip as standard, to prevent possible personal injury and damage to clothing as with the 15mm lip. A 5mm lip extension is included with the strike if needed. Fail safe/fail secure is changeable on site. LOX High Security is successfully fire rated up to 4hrs on fire door assemblies in accordance with AS/NZS 1905, Part 1-1997 and BS 476: Part 22-1987 (Fire resistant door sets).

Tags

hinge electric strike multi voltage high security

Product Details

Product: LOX High Security Electric Strike Non-Monitored Multi Voltage 10-30VDC ES20
Category: Door and Window Hinges
Sold by: Keeler Hardware

Keeler Hardware is specified by

(29) Professionals

LOX High Security Electric Strike Non-Monitored Multi Voltage 10-30VDC ES20

Visit site

Retrofit compatible with FSH and Padde Australian Footprint strikes. It comes with a 10mm strike lip as standard, to prevent possible personal injury and damage to clothing as with the 15mm lip. A 5mm lip extension is included with the strike if needed. Fail safe/fail secure is changeable on site. LOX High Security is successfully fire rated up to 4hrs on fire door assemblies in accordance with AS/NZS 1905, Part 1-1997 and BS 476: Part 22-1987 (Fire resistant door sets).

LOX High Security Electric Strike is designed for use with all access control systems.

Specs: Voltage: 10 - 30VDC, 250mA at 12VDC, 125mA AT 24VDC

Current: 12vdc @ 250mA, 24vdc @ 125mA,

Holding Strength: up to 1000kg Tested to 1.5 Million Cycles

LSS Monitoring: Status sensor of the internal locking mechanism

DSS Monitoring: Door latch sensor, door latch engaged within strike keeper

ATS Monitoring: Door strike removed or repositioned sensor

Temperature: Range - 20 degress celcius to 60 degrees celcius

Material: Stainless Steel
Features: Non Monitored

Fire rated up to 4 hours

Power to lock/power to open field selectable

Solenoid can be continuously powered

Optional extension lips

Self adhesive installation template

Includes tab mounting kit

Pre-drilled for extension lips

Supplied with silencer rubber buffer

ES20 is suitable for 18mm latch with a 3mm door gap
